Connecting rod servo (rv reducer) sprayer

1.It adopts linkage structure, RV reducer is equipped with servo drive, which has high mechanical strength, good stability and
long service life.
2.It can be single-acting or connected with die-casting machine and soup-feeding machine for fully automatic production
3.It can be equipped with copper tube nozzles or modular nozzles, and can be interchanged.
4.The atomization amount of the modular nozzle can be adjusted individually, the spray control method: front left and right separate spray, front middle spray, rear left and right separate spray, rear middle spray; blowing control method: front and rear copper pipes blowing at the same time or the spray mode is changed to blowing mode. (Note: ESSC2# comes standard with front single spray and rear single spray. If you need front left and right spray separately, front middle spray, rear left and right spray separately, and rear middle spray, please contact our company!)
Copper tube spray control method: any one spray or simultaneous spray before, middle and rear. Blow control method: any one blow or simultaneous blow before, middle and rear。
5.The X-axis base has the function of adjusting the thickness of the motor mold, which saves time, effort and safety.
6.The Y-axis arm stays at any point to do fixed-point spray, circulating spray, floating spray and air blowing.
7.It is possible to add and store multiple sets of mold painting programs in the system according to the requirements. When changing molds, directly call the stored programs in the man-machine interface to use directly, making operation and maintenance convenient.
